AUTOMATIC CLEANER – MOD. WP BF4
- Brand: GRAF Synergy
- Year: 2011
- Revision and Testing: Operating
- Warranty: No
- Graf Synergy On consignment
- Description: Automatic Cleaner – Mod. WP BF4
Flat surfaces weld beads cleaning by means of pneumatic grooved knives.
Frame profiles recognition system.
Milling head corner external side cleaning
2 vertical knives corner internal side cleaning
External corner 4 cutters assembly preset
Enable and disable of each operation
Automatic operating cycle start-up by placing the workpiece into the machine
Product Details
Profile height automatic clamps setting
Axial and vertical motion on ball bearings and ground-hardened ways, without wear.
All motions speeds setting
Top and bottom flat surfaces cleaning knives.
Top and bottom seal channels drills
Pair of profile supporting arms.
Filter/reducer lubricator unit for pneumatic system
No. 4 cutter sleeves
Cutters adjustment SSC spacers kit
6 m hose air gun
1 litre oil-can for pneumatic system lubrication
Dimensions
Length: 1.800 mm
Width: 1.100 mm
Height: 1.750 mm
Weight: 650 Kg
power supply and consumption
Supply: 400 V
Installed power: 1.2 Kw
Air consumption per cycle: 110 Nl/min.
Blade Dimensions: –
